Description
This air heater provides rapid heating and high thermal efficiency, ensuring reliable performance in high-temperature environments, specifically tailored for SOFC hydrogen energy applications.
Hydrogen Energy Users – Efficient Heating Solution
Rapid Heating
Achieves up to 1000°C in just 10 seconds, ensuring quick start-up and reduced downtime.
High Thermal Efficiency
High watt density design allows for efficient heat transfer, maximizing energy utilization.
Long Working Life
With a potential lifespan of up to 10 years or 90,000 hours, it offers durability and reliability.
Oxidation & Chemical Resistance
Constructed with materials that resist oxidation and chemical corrosion, ensuring longevity in harsh environments.
Features
The air heater is made of Silicon Nitride (Si3N4), a material known for its high-temperature stability and chemical resistance. It offers a voltage range of 12V/24V/48V/120V/220V and power options of 45W/75W or customized. The flange can be ceramic or customized, and it operates within a temperature range of 1100~1300°C (2012~2372°F). Ignition time is rapid, reaching up to 1000°C in 10 seconds.
Benefits
Customers benefit from the air heater’s rapid heating capability, which reduces start-up time and increases productivity. Its high thermal efficiency ensures optimal energy use, lowering operational costs. The long working life and resistance to oxidation and chemicals provide peace of mind and reduce maintenance needs. Additionally, the customizable options cater to specific application requirements, enhancing versatility.
Use Cases
This air heater is ideal for use in gas furnaces, burners, kilns, and other heating equipment. It is particularly suited for gas or hydrogen water heaters, boilers, SOFC, and PEFC fuel cell MCHP burner and reformer units. Applications also include gas reforming to H2, H2 post-gas combustion, laboratory equipment, biomass boiler secondary combustion, hydrogen combustion, and flame detection in H2 combustion burners. Its versatility makes it a valuable addition to any high-temperature heating system.
| Name | HSHF 0401 Si3N4 Heater For SOFC Hydrogen Energy | |
| Model | HSHF 0401 Up to 1200-1350℃ | |
| Material | Silicon Nitride (Si3N4) | |
| Voltage | 12V/24V/48V/120V/220V | |
| Power | 45W/75W/Customized | |
| Flange | Ceramic/Customized | |
| Temp Range | 1100~1300 °C/2012~2372℉ | |
| Ignition Time | up to 1000°c in 10 seconds | |
| Samples fee | Please contact us for confirmation. | |
| Packing | Carton | |
| Lead time | 5 working days for samples; 12 working days for mass production | |
| QC | Strict quality control under SGS, ISO9001 and Intertek. | |
| Certification | BSCI, ISO9000/1400,BV TUV SGS FSC etc. | |
| Applications Gas furnace,burner,kiln Gas or hydrogen water heater,boiler or other heating equipment SOFC,PEFC Fuel Cell MCHP burner and reformer unit Gas reforming to H2 H2 Post gas combustion Laboratory equipment Biomass boiler secondary combustion Hydrogen combsution Flame detection in H2 combustion burner |
||
| ·Rapid heating: Heating faster. up to 1000°c in 10 seconds ·Range of temperature:1100~1300 °C/2012~2372℉ ·Small size / High watt density: High-watt density discharge allow high thermal efficiency. ·Long working life:10 years possible,90,000 hours ·High insulation ·Direct water and kerosene heating ·Vacuum environment ·Oxidation and chemical resistance |
||
Why Choose Our Air Heater?
Our air heater stands out for its rapid heating capability, achieving up to 1000°C in just 10 seconds. It offers high thermal efficiency, long working life, and resistance to oxidation and chemicals, making it ideal for high-temperature applications in the hydrogen energy sector.
Key Features
The air heater is made of Silicon Nitride (Si3N4), ensuring durability and chemical resistance. It provides a voltage range of 12V/24V/48V/120V/220V and power options of 45W/75W or customized. The temperature range is 1100~1300°C, and it features a rapid ignition time.
Versatile Applications
This air heater is suitable for a wide range of applications, including gas furnaces, burners, kilns, and hydrogen energy systems. Its customizable options cater to specific needs, enhancing its versatility and value.
