Description
Our gas furnace igniter provides a reliable and cost-effective replacement solution, ensuring consistent ignition and minimizing downtime.
Homeowners – Solve Ignition Issues with Reliable Gas Furnace Igniter
96% Alumina Material
Enhances durability and heat resistance, ensuring long-lasting performance.
Quick Ignition Time (40-60 seconds)
Reduces waiting time for heating, improving user experience.
Wide Temperature Range (30~1050°C)
Adapts to various heating environments, ensuring reliable ignition.
Customizable Flange Options
Offers flexibility in installation, catering to different gas furnace models.
Features
The HF1304 Series Ceramic Igniter is crafted from 96% alumina, providing exceptional heat resistance and durability. It operates at a voltage of 220V with a power rating of 150W, ensuring efficient ignition. The igniter features a customizable flange, available in ceramic, stainless steel, copper, or customized options, to fit various gas furnace models. With a temperature range of 30~1050°C, it adapts to diverse heating environments.
Benefits
By choosing our gas furnace igniter, customers benefit from quick ignition times (40-60 seconds), reducing waiting time for heating. The durable construction ensures long-lasting performance, minimizing the need for frequent replacements. The customizable flange options provide installation flexibility, catering to different gas furnace models. Additionally, the wide temperature range ensures reliable ignition in various heating environments, enhancing user satisfaction.
Use Cases
Our gas furnace igniter is ideal for a wide range of applications, including biomass boilers/burners, pellet burners, gas burners/stoves, pellet boilers, and ignition of gas or oil. It is also suitable for pellet stoves, pellet BBQ grills, stove fireplaces, medical-scientific equipment, wood pellet stoves, heaters-agricultural systems, particle burning, spark igniters, fuel cells, EV heating, gas appliances, glow plugs, petroleum equipment, cabin heaters, soldering irons, gas sensors, gas furnaces, DPF/Catalysts, and gas boilers. This versatility makes it a valuable addition to any heating system.
| Name | Ceramic Igniter |
| Model | HF1304 Series |
| Material | 96% alumina |
| H.S. Code | 8516800000 |
| Voltage | 220V |
| Power | 150W |
| Flange | Ceramic/Stainless Steel/copper/customized |
| Temp Range | 30~1050 °C/86~1922℉ |
| Ignition Time | 40-60 seconds |
| Samples fee | Please contact for confirmation. |
| Packing | carton |
| Lead time | 5 working days for samples; 12 working days for mass production |
| QC | Strict quality control under SGS, ISO9001 and Intertek. |
| Certification | BSCI, ISO9000/1400,BV TUV SGS FSC etc. |
| Applications | |
| Biomass boiler/burner | Pellet burners |
| Gas burner/stove | Pellet boiler |
| Ignition of gas or oil | Pellet burner |
| Pellet Stove | Pellet BBQ grill |
| Stove fireplace | Medical-Scientific |
| Wood pellet stove | Heaters-Agricultural |
| Particle Burning | Spark Igniters |
| Fuel cells | EV heating |
| Gas appliances | Glow plug |
| Petroleum equipment | Cabin heater |
| Soldering iron | Gas sensor |
| gas furnaces, | DPF/Catalyst |
| gas boiler | |
| Model Number | Voltage(V) | Rating power(W) | OD.tube(mm) | Total length L1(MM) | Max.OD.flange(MM) |
| HF1304A01-B | 220 | 150 | 22 | 170 | 20 |
Why Choose Our Gas Furnace Igniter?
Our gas furnace igniter offers a reliable and cost-effective solution for ignition issues. With quick ignition times and a wide temperature range, it ensures consistent heating performance. The customizable flange options provide installation flexibility, catering to different gas furnace models.
How Does It Solve Common Ignition Problems?
Our igniter addresses common issues such as gas furnace igniter not lighting, not glowing, and replacement costs. Its durable construction and efficient ignition minimize downtime and maintenance costs, providing a hassle-free heating experience.
What Makes It Stand Out from Competitors?
Our gas furnace igniter stands out with its 96% alumina material, quick ignition time, and wide temperature range. The customizable flange options and strict quality control under SGS, ISO9001, and Intertek ensure superior performance and reliability, setting it apart from competitors.
