Description
Delivers instant ignition and thermal stability for industrial heating systems, reducing downtime and energy consumption.
Industries – Achieve Instant Ignition with Silicon Nitride
10-Second Rapid Heating
Reaches 1000°C in 10 seconds, cutting preheating time by 70% compared to traditional igniters.
1100-1300°C Temperature Range
Withstands extreme heat environments in hydrogen combustion systems and kilns.
90,000-Hour Lifespan
10-year operational durability under continuous high-temperature conditions.
Oxidation & Chemical Resistance
Silicon nitride construction prevents corrosion in acidic/alkaline environments.
Features
Material: Silicon Nitride (Si3N4) with ceramic/stainless steel flange options
Voltage: 24V DC, Power: 120W
Temperature Range: 1100-1300°C (2012-2372°F)
Ignition Time: ≤10 seconds to 1000°C
Certifications: BSCI, ISO9000/1400, BV TUV SGS FSC
Quality Control: SGS/ISO9001/Intertek compliant
Benefits
Energy Efficiency: Reduces preheating time by 70%, lowering operational costs
Maintenance-Free: 90,000-hour lifespan minimizes replacement frequency
Safety Compliance: Meets global industrial safety standards (ISO/SGS)
Versatility: Customizable flanges for gas furnaces, hydrogen boilers, and lab equipment
Environmental Resistance: Withstands vacuum conditions and direct water/kerosene exposure
Use Cases
Industrial Furnaces: Gas/hydrogen kilns, biomass boiler secondary combustion
Energy Systems: SOFC/PEFC fuel cell reformers, hydrogen post-combustion units
Domestic Appliances: Gas water heaters, boiler ignition systems
Laboratory Equipment: High-temperature experimental reactors
Specialty Applications: Flame detection in hydrogen combustion burners
| Name | Silicon Nitride Igniter Hot Surface Ignitor | |
| Model | HF0004025 Si3N4 Heater For SOFC Hydrogen Energy 24V/120W | |
| Material | Silicon Nitride (Si3N4) | |
| Voltage | 24V | |
| Power | 120w | |
| Flange | Ceramic/Stainless Steel/Copper/Customized | |
| Temp Range | 1100~1300 °C/2012~2372℉ | |
| Ignition Time | up to 1000°c in 10 seconds | |
| Samples fee | Please contact us for confirmation. | |
| Packing | Carton | |
| Lead time | 5 working days for samples; 12 working days for mass production | |
| QC | Strict quality control under SGS, ISO9001 and Intertek. | |
| Certification | BSCI, ISO9000/1400,BV TUV SGS FSC etc. | |
| Applications Applications Gas furnace,burner,kiln Gas or hydrogen water heater,boiler or other heating equipment SOFC,PEFC Fuel Cell MCHP burner and reformer unit Gas reforming to H2 H2 Post gas combustion Laboratory equipment Biomass boiler secondary combustion Hydrogen combsution Flame detection in H2 combustion burner |
||
| ·Rapid heating: Heating faster. up to 1000°c in 10 seconds ·Range of temperature:1100~1300 °C/2012~2372℉ ·Small size / High watt density: High-watt density discharge allow high thermal efficiency. ·Long working life:10 years possible,90,000 hours ·High insulation ·Direct water and kerosene heating ·Vacuum environment ·Oxidation and chemical resistance |
||
Why Choose This Hot Surface Ignitor?
Engineered for hydrogen energy systems and industrial furnaces, this silicon nitride igniter achieves 1000°C in 10 seconds while offering 10-year durability. Certified for global safety standards (ISO/SGS), it reduces energy consumption by 30% compared to conventional models.
Key Advantages Over Competitors
Competitors' ceramic igniters require 30+ seconds to reach operational temperature and fail after 20,000 hours. Our product's silicon nitride composition enables 4x longer lifespan and 3x faster heating, with built-in resistance to hydrogen corrosion.
Technical Specifications
24V/120W power rating, 1100-1300°C operating range, and customizable flange options (ceramic/stainless steel) ensure compatibility with SOFC fuel cells, gas reformers, and laboratory burners. Strict SGS/ISO9001 quality control guarantees reliability.
