Description
Delivering high-performance heating solutions tailored for SOFC hydrogen energy systems, ensuring optimal efficiency and reliability.
Hydrogen Energy Users – Efficient Heating with Si3N4 Heater
Rapid Heating
Achieves up to 1000°C in just 10 seconds, boosting operational efficiency.
High Temperature Range
Operates from 1100°C to 1300°C, suitable for demanding hydrogen energy applications.
Long Lifespan
Potential lifespan of up to 10 years or 90,000 hours, reducing replacement costs.
High Insulation
Ensures safe and efficient operation, minimizing energy loss.
Features
The Si3N4 Heater for SOFC Hydrogen Energy features a robust silicon nitride (Si3N4) construction, ensuring durability and resistance to oxidation and chemicals. It operates within a voltage range of 90V-110V and offers customizable power options from 35W-60W. The heater is equipped with a choice of ceramic or stainless steel flanges, catering to various installation requirements.
Benefits
This heater provides rapid heating capabilities, reaching up to 1000°C in just 10 seconds, which significantly enhances operational efficiency. Its high temperature range from 1100°C to 1300°C makes it ideal for demanding hydrogen energy applications. The long lifespan of up to 10 years or 90,000 hours reduces the need for frequent replacements, saving costs. Additionally, the high insulation ensures safe and efficient operation, minimizing energy loss and maximizing performance.
Use Cases
The Si3N4 Heater is perfectly suited for a wide range of hydrogen energy applications, including gas furnaces, burners, kilns, and boilers. It is also ideal for SOFC and PEFC fuel cell MCHP burner and reformer units, gas reforming to H2, H2 post-gas combustion, and laboratory equipment. Furthermore, it finds applications in biomass boiler secondary combustion, hydrogen combustion, and flame detection in H2 combustion burners, offering versatile and reliable heating solutions.
| Name | HFHS 1401 Si3N4 Heater For SOFC Hydrogen Energy | |
| Model | HFHS 1401 Up to 1200-1350℃ | |
| Material | Silicon Nitride (Si3N4) | |
| Voltage | 90V-110V | |
| Power | 35W-60W Customized | |
| Flange | Ceramic/Stainless Steel/Customized | |
| Temp Range | 1100~1300 °C/2012~2372℉ | |
| Ignition Time | up to 1000°c in 10 seconds | |
| Samples fee | Please contact us for confirmation. | |
| Packing | Carton | |
| Lead time | 5 working days for samples; 12 working days for mass production | |
| QC | Strict quality control under SGS, ISO9001 and Intertek. | |
| Certification | BSCI, ISO9000/1400,BV TUV SGS FSC etc. | |
| Applications
Gas furnace,burner,kiln |
||
| ·Rapid heating: Heating faster. up to 1000°c in 10 seconds ·Range of temperature:1100~1300 °C/2012~2372℉ ·Small size / High watt density: High-watt density discharge allow high thermal efficiency. ·Long working life:10 years possible,90,000 hours ·High insulation ·Direct water and kerosene heating ·Vacuum environment ·Oxidation and chemical resistance |
||
Why Choose Our Si3N4 Heater?
Our Si3N4 Heater stands out for its rapid heating, high temperature range, and long lifespan, making it the ideal choice for hydrogen energy applications. It ensures optimal efficiency and reliability, reducing operational costs and enhancing performance.
How Does It Benefit Hydrogen Energy Systems?
The Si3N4 Heater provides precise temperature control, high insulation, and resistance to oxidation and chemicals, ensuring safe and efficient operation in hydrogen energy systems. Its rapid heating capabilities significantly enhance operational efficiency, while its long lifespan reduces the need for frequent replacements.
What Are Its Key Applications?
The Si3N4 Heater is widely used in gas furnaces, burners, kilns, boilers, SOFC and PEFC fuel cell units, gas reforming to H2, H2 post-gas combustion, laboratory equipment, biomass boiler secondary combustion, hydrogen combustion, and flame detection in H2 combustion burners.
