Description
Our Si3N4 Heater delivers ultra-fast heating, high-temperature resistance, and long-lasting performance for SOFC hydrogen energy systems, ensuring efficient and reliable operation.
Hydrogen Systems – Boost Efficiency with Si3N4 Heater
Ultra-Fast Heating
Reaches up to 1000°C in just 10 seconds, significantly reducing startup time.
High-Temperature Resistance
Operates reliably between 1100°C and 1300°C, suitable for extreme environments.
Long Working Life
Up to 10 years or 90,000 hours of operation, minimizing replacement costs.
High Insulation
Ensures safety and efficiency by preventing heat loss and electrical hazards.
Features
The Si3N4 Heater for SOFC Hydrogen Energy features a silicon nitride (Si3N4) construction, offering exceptional thermal stability and chemical resistance. It supports voltages from 12V to 220V and powers ranging from 30W to customized options. The heater comes with ceramic or stainless steel flanges and can be tailored to specific requirements.
Benefits
Our Si3N4 Heater provides rapid heating, reducing downtime and increasing productivity. Its high-temperature resistance ensures reliable performance in demanding environments, while its long working life lowers maintenance costs. The high insulation properties enhance safety and energy efficiency, making it an ideal choice for hydrogen energy systems.
Use Cases
This heater is widely used in gas furnaces, burners, kilns, and hydrogen water heaters. It is essential for SOFC and PEFC fuel cell MCHP burner and reformer units, gas reforming to H2, H2 post-gas combustion, and laboratory equipment. Its oxidation and chemical resistance make it suitable for biomass boiler secondary combustion and flame detection in H2 combustion burners.
| Name | HSHF 12/24 Si3N4 Heater For SOFC Hydrogen Energy | |
| Model | HSHF 12/24 Up to 1200-1350℃ | |
| Material | Silicon Nitride (Si3N4) | |
| Voltage | 12V/24V/48V/120V/220V | |
| Power | 30W/40W/Customized | |
| Flange | Ceramic/Stainless Steel/Customized | |
| Temp Range | 1100~1300 °C/2012~2372℉ | |
| Ignition Time | up to 1000°c in 10 seconds | |
| Samples fee | Please contact us for confirmation. | |
| Packing | Carton | |
| Lead time | 5 working days for samples; 12 working days for mass production | |
| QC | Strict quality control under SGS, ISO9001 and Intertek. | |
| Certification | BSCI, ISO9000/1400,BV TUV SGS FSC etc. | |
| Applications Gas furnace,burner,kiln Gas or hydrogen water heater,boiler or other heating equipment SOFC,PEFC Fuel Cell MCHP burner and reformer unit Gas reforming to H2 H2 Post gas combustion Laboratory equipment Biomass boiler secondary combustion Hydrogen combsution Flame detection in H2 combustion burner |
||
| ·Rapid heating: Heating faster. up to 1000°c in 10 seconds ·Range of temperature:1100~1300 °C/2012~2372℉ ·Small size / High watt density: High-watt density discharge allow high thermal efficiency. ·Long working life:10 years possible,90,000 hours ·High insulation ·Direct water and kerosene heating ·Vacuum environment ·Oxidation and chemical resistance |
||
Why Choose Our Si3N4 Heater?
Our Si3N4 Heater stands out with its ultra-fast heating, high-temperature resistance, and long working life. It is designed specifically for hydrogen energy systems and fuel cell applications, ensuring efficient and reliable operation.
How Does It Benefit Your Business?
By reducing startup time and maintenance costs, our heater enhances productivity and profitability. Its high insulation properties also improve safety and energy efficiency.
Where Can It Be Applied?
This versatile heater is suitable for a wide range of applications, including gas furnaces, burners, kilns, and hydrogen water heaters. It is essential for SOFC and PEFC fuel cell systems, gas reforming, and laboratory equipment.
