Description
Delivers reliable high-temperature heating with extended durability for hydrogen energy systems.
Hydrogen Innovators – Achieve 1000°C in 10s with Si3N4 Heaters
Rapid Heating Capability
Reaches 1000°C in 10 seconds, boosting operational efficiency
10-Year Lifespan Potential
90,000+ hours of reliable performance reduces replacement costs
High Watt Density Design
Compact size delivers 35W-60W output for space-constrained installations
Multi-Material Flange Options
Customizable ceramic/stainless steel flanges for diverse system integrations
Features
The HFHS-1405 Si3N4 Heater features silicon nitride construction with 1100-1300°C operating range, 90-110V input, and 35-60W adjustable power. Available with ceramic/stainless steel flanges and IP65 insulation rating. Meets SGS, ISO9001, and Intertek standards.
Benefits
Engineered for hydrogen energy systems, this heater reduces energy consumption by 30% through rapid heating while maintaining stability in vacuum environments. The oxidation-resistant Si3N4 material extends service life 5x longer than conventional heaters, lowering total ownership costs.
Use Cases
Ideal for SOFC/PEFC fuel cell reformers, hydrogen water heaters, biomass boilers, and laboratory equipment. Used in gas reforming processes, post-combustion systems, and flame detection applications across energy, industrial, and research sectors.
| Name | HFHS 1405 Si3N4 Heater For SOFC Hydrogen Energy | |
| Model | HFHS 1405 Up to 1200-1350℃ | |
| Material | Silicon Nitride (Si3N4) | |
| Voltage | 90V-110V | |
| Power | 35W-60W Customized | |
| Flange | Ceramic/Stainless Steel/Customized | |
| Temp Range | 1100~1300 °C/2012~2372℉ | |
| Ignition Time | up to 1000°c in 10 seconds | |
| Samples fee | Please contact us for confirmation. | |
| Packing | Carton | |
| Lead time | 5 working days for samples; 12 working days for mass production | |
| QC | Strict quality control under SGS, ISO9001 and Intertek. | |
| Certification | BSCI, ISO9000/1400,BV TUV SGS FSC etc. | |
| Applications
Gas furnace,burner,kiln |
||
| ·Rapid heating: Heating faster. up to 1000°c in 10 seconds ·Range of temperature:1100~1300 °C/2012~2372℉ ·Small size / High watt density: High-watt density discharge allow high thermal efficiency. ·Long working life:10 years possible,90,000 hours ·High insulation ·Direct water and kerosene heating ·Vacuum environment ·Oxidation and chemical resistance |
||
Why Choose This Heater?
The HFHS-1405 combines silicon nitride's thermal stability with rapid heating capabilities, making it ideal for hydrogen energy applications requiring precise temperature control and long-term reliability.
Key Differentiators
Unlike metal-based heaters, our Si3N4 model resists oxidation at 1300°C while maintaining 90% efficiency over 90,000 hours. The customizable flange system enables seamless integration with existing hydrogen infrastructure.
Technical Superiority
Certified by BSCI, ISO9001, and TUV SGS, this heater exceeds industry standards for safety and performance in high-pressure hydrogen environments.
